Made in the USA. Includes two MiniRails — one for each wingtip.

The KBar MiniRails are built for smaller electric RC airplanes (48"–68") where every gram counts. At under 25 g in flight, they keep your setup nimble while delivering serious glow. They mount using your existing SFG holes and remain fully compatible with Side Force Generators (SFGs), so installation stays clean and both CG and roll balance remain dialed in.

Engineered with balanced LED arrays, diffusers, and anti-shine caps, the MiniRails reduce eye strain and produce a smooth, even glow — creating a more comfortable and balanced night-flying experience.

Specs:

• Weight: 18.5 g (without battery)
• Battery: 1S LiPo — HV (4.35 V) or Standard (4.20 V)
• Plug: JST PH 2.0
• Lumens: 663 per Light
• Color Temp: 5700 K (Natural White)
• Projection Angle: 115°
• Hole Specs: 52.7 mm – 123.7 mm

Runtime Options:

• 24.4 Grams, 1S 150 mAh (4.2 V), ~12 minutes
• 30.5 Grams, 1S HV 450 mAh (4.35 V), ~35 minutes

Overview:

• Construction: 1mm Aircraft-Grade, Anodized Aluminum with matte black powder coat — doubling as a built-in heatsink.
• Versatile: Flexible and durable design lets you fine-tune light projection.
• Field-friendly: Quick-swap lights make repairs simple.

Recommended:

• 1S 150 mAh - https://a.co/d/iMJQcjr
• 1S 450 mAh HV - https://a.co/d/h9VbHJ7
• Charger - https://a.co/d/22bL5KX

Notes:

• Designed exclusively for electric aircraft (not compatible with gas or glow).
• Images shown are illustrative; actual product may vary with updates.
